Ubiquiti Device Bridge Switch
€ 432,50
Artikelnummer:
69051
| Beheerfuncties | |
|---|---|
| Switch type | Managed |
| Poorten & interfaces | |
|---|---|
| Aantal basis-switching RJ-45 Ethernet-poorten | 8 |
| Aantal 2,5 Gbit RJ-45 Poorten | 7 |
| Aantal 10 Gbit RJ-45 Poorten | 1 |
| Netwerk | |
|---|---|
| 10G support | Ja |
| Design | |
|---|---|
| Materiaal behuizing | Polycarbonaat |
| Prestatie | |
|---|---|
| WiFi versie | WiFi-7 |
| MIMO 6 GHz | 2 x 2 |
| MIMO 5 GHz | 2 x 2 |
| Max. Data Rate 6 GHz | 5.8 Gbps (BW320) |
| Max. Data Rate 5 GHz | 4.3 Gbps (BW240) |
| Antenneversterking 6 GHz | 8 dBi |
| Antenneversterking 5 GHz | 8 dBi |
| Max. TX Power 6 GHz | 23 dBm |
| Max. TX Power 5 GHz | 26 dBm |
| Draadloze beveiliging | WPA3 SAE (Always On) |
| 802.11be (WiFi 7) | GHz: 7,3 Mbps tot 5,8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) 5 GHz: 7,3 Mbps tot 4,3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240) |
| 802.11ax (WiFi 6) | 7,3 Mbps tot 2,4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| 802.11ac (WiFi 5) | 6,5 Mbps tot 1,7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) |
| 802.11n | 6,5 Mbps tot 300 Mbps (MCS0 - MCS15, HT 20/40) |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Energie | |
|---|---|
| Vermogensverbruik (max) | 25W (zonder PoE output) |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Ja |
| Aantal Power over Ethernet plus (PoE +)-poorten | 8 |
| Totaal Power over Ethernet (PoE)-budget | 35W (inbegrepen adaper)185W (optionele adapter) |
| Overige specificaties | |
|---|---|
| Afmetingen (BxDxH) | 212.9 x 113 x 32.5 mm |
| Type product | Device Bridge Switch |
| Verpakking | |
|---|---|
| Inclusief AC-adapter | 54V DC/1.1A (inbegrepen) |
| Netwerk | |
|---|---|
| Maximale snelheid | 10000 Mbit/s |
| Design | |
|---|---|
| Kleur van het product | Wit |
| Display | 2,4cm LCM display |
